Camera |
Image Sensor |
1/3" sensor |
Min. Illumination |
0.014lux @(F1.4,AGC ON) 0 lux with IR |
Shutter Speed |
1/25s ~ 1/100,000s |
Lens |
2.8 ~ 12mm @ F1.4, Angle of view: 113°-33.8° |
Lens mount |
Φ14 |
Day & Night |
ICR |
ROI |
Yes, up to 4 configurable areas |
Digital Noise Reduction |
3D DNR |
Wide Dynamic Range |
Digital WDR |
Backlight compensation |
Yes,zone optional |
Compression Standard |
Video Compression |
H.264 / MJPEG |
H.264 compression profile |
Main profile |
Bit Rate |
32 Kbps ~ 16 Mbps |
Audio Compression |
G.711/G.726/MP2L2 |
Audio Bit Rate |
64Kbps(G.711) / 16Kbps(G.726)/ 32~128Kbps(MP2L2) |
Dual Stream |
Yes |
Image |
Max. Resolution |
1920×1080 |
Frame Rate |
60Hz: 30fps (1920×1080) 50Hz: 25fps (1920×1080) |
Image Settings |
Saturation, brightness, contrast adjustable through client software or web browser |
Network |
Network Storage |
NAS |
Alarm Trigger |
Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage full , Storage error |
Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP, SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
System Compatibility |
ONVIF, PSIA, CGI, ISAPI |
General functionalities |
User Authentication, Watermark |
Interface |
Communication Interface |
1 RJ45 10M / 100M ethernet port |
On-board Storage |
Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB |
Audio Input/Output |
1/1 |
Alarm Input/Output |
1/1 |
General |
Working Temperature /Humidity |
-22 °F ~ 140 °F(-30 °C ~ 60 °C) , humidity 95% or less (non-condensing) |
Power Supply |
DC12V ± 10%, PoE (802.3af) |
Power Consumption |
Max. 7.5W |
Impact protection |
IEC60068-2-75Eh, 50J; EN50102, up to IK10 |
Ingress protection level |
IP66 |
IR Range |
Up to 100ft(About 30 meters) |
Dimension |
3.7" × 4.1" × 10.2"(95.0×105.0×258.6 mm ) |
Weight |
2.6lbs(1200g) |
